05 SCFM (0.11m3/hr), it not only costs less to buy, it costs less to operate as well. With flow rates up to 12 SCFM(20m3/hr), the 950XP has the muscle to drive large valves and actuators.
Advanced circuitry includes electronic feedback control for superior vibration protection and highly accurate output. Its NEMA 4X (IP66) housing is designed for both Intrinsically Safe* and Explosion-Proof* operation. Now there's a compact I/P transducer that delivers reliable high performance for the toughest applications in the most hazardous environments: the T950XP from ControlAir.The 950XP converts an electrical current signal to a stable, pneumatic output to actuate valves. The ControlAir Type-925 Multifunction Manifold provides a common supply port and individual shutoff valves for sets of 3, 5, 10 or 15 units. In addition to standard wall, panel or pipe mounting, optional DIN rail and manifold mounting kits are available. Multiple choices for wiring and porting simplify installation and decrease the time required to do so. The Type-595XP has worldwide agency approvals for use in hazardous areas. This explosion-proof and intrinsically safe field device is available with an integral volume booster or as a low-flow signal converter that directly mounts to a pneumatic valve positioner. This compact unit is housed in an explosion proof enclosure that is designed for pipe, bracket or direct manifold mounting. A low mass control circuit provides consistent output in high vibration applications. The unique conversion technology utilizing open loop control provides a high level of accuracy and repeatability for the operation of actuated valves. The Type-595XP Explosionproof I/P (current to pressure) transducer converts a 4–20mA electrical current signal to a proportionally linear pneumatic output. This filter is an economical alternative for air supply line applications that don't require a pressure reducing regulator. Robustly constructed of die-cast aluminum with a baked epoxy finish, this unit stands up in corrosive operating conditions. The Type-320 Filter unit is a 40-micron depth filter that removes dirt, moisture and other particles from air and gas lines. Designed specifically for corrosive sour gas environments, the Type-310 NACE is ideal for oil field applications. The Type-310 NACE Filter Regulator incorporates all of the operating features of the Type-300 filter regulator, but is constructed of materials that meet NACE specification #MR-01-75 for sulfide stress cracking. The Type-300 is a quality unit that is ideal as an economical alternative for control of process applications.
Durable materials and a standard epoxy paint finish provide long lasting corrosion resistance in harsh industrial environments. This filter regulator has been proven to provide accurate operating characteristics under variable conditions. Optional Negative Bias 4 psi (0.3 bar) negative bias of signal pressure to 'zero' I/P's Flow, scfm (nl/min) Supply Pressure: 100 psig (7.9 bar) Cv: 4.5 Flow, scfm (nl/min) Output Pressure psig (bar) Supply Pressure: 100 psig (7.9 bar) Cv: 2 Regulated Pressure vs Flow: 3/4” Type 6100/6200 Output Pressure psig (bar) Output Pressure psig (bar) Supply Pressure: 100 psig (7.The Type-300 Instrument Air Filter Regulator is designed to provide clean, accurate air pressure to instruments, valves, and other automatic control equipment.Balanced Supply Valve Minimizes the effect of supply pressure variation.High Output Exhaust Vents (2) 1/4" NPT tapped exhaust (Type 6100 option) 1/2" NPT tapped exhaust (Type 6200 standard).High Temperature Operation Up to 200☏ (93☌).Soft Valve Seat Design Provides tight shutoff and eliminates leakage in steady state operation.High Flow Capacity For rapid actuator stroking.Integral Adjustable Bypass Valve Allows small incremental signal changes without opening the primary valve.
Aluminum or 316 Stainless Steel Construction.The bypass valve is used to adjust dynamic response to provide stable operation over a wide range of actuator sizes. A fixed deadband and adjustable bypass valve combine to allow small incremental downstream adjustment without opening the main booster valve. They are suitable for either diaphragm or piston actuators. Typically they are used to increase throttling speed of large volume valve actuators. The Type 6100 is constructed of aluminum and the Type 6200 is constructed of 316 stainless steel. High Flow Capacity Volume Booster Rapid stroke capability in rugged aluminum or 316 stainless steel construction The ControlAir Type 6100/6200 volume booster is a 1:1 signal to output relay that is utilized in applications that require high forward flow and exhaust capacities.
